Aluminium In-line Sliding and Lift & Slide Doors Specialists, Staffordshire
Patio Sliding Doors from Andrew James Home Improvement LTD are more than just nice to look at, they offer strength, stability and excellent impact resistance.
High performance with stunning design
Our ‘In-line Sliding’ and ‘Lift & Slide’ doors provide a versatile solution for any architectural project. They’re ensured by thick profile walls, internal webs and the use of galvanised steel reinforcement. Angled external faces deflect dirt and water, as well as enhancing the good looks.
Aluminium In-line Sliding and Lift & Slide Doors
'Choices' Optio 'BSC94' In-line Sliding and Lift and Slide options
Standard Interlock
Threshold and Sash
As overall sizes increase, additional external reinforcing will be required
Standard Design Features
- 28mm sealed units
- 4 hook locks (Slider only)
- Black or white handles
- Black buffer stops
- 'U' value 1.7 W/m2K with double glazing
- Dual rail
Optional 45mm Slim Interlock - Sliding and Lift and Slide
Upgrades/Options
- A range of RAL single or dual colour
- Brushed chrome handles
- Triple track slider - no cill available - 155mm frame
- 45mm slim interlock
BSC94 Door Configurations
View the various door configurations on offer with the Optio 'BSC94' In-line Sliding and Lift and Slide doors
In-line Sliding Doors
2 Pane
Minimum width 1400mm (at 2100mm high)
Maximum width 4000mm
Maximum Height 2300mm
3 Pane
Minimum width 2700mm
Maximum width 6000mm
Maximum Height 2300mm
4 Pane
Minimum width 3600mm
Maximum width 6000mm
Maximum Height 2300mm
Lift and Slide Doors
2 Pane
Minimum width 1400mm (at 2100mm high)
Maximum width 4000mm
Maximum Height 2400mm
3 Pane
Minimum width 2700mm
Maximum width 6000mm
Maximum Height 2400mm
4 Pane
Minimum width 3600mm
Maximum width 6000mm
Maximum Height 2400mm
Configurations: Door sash width cannot be less than 3x smaller than the height of the door
Colour Range for Fast Delivery
White RAL 9910hg
Anthracite Grey RAL 7016m
Anthracite Grey / White
Available in any Single or Dual RAL Colour
(Extended Lead Time)
The 'Choices' range of Aluminium Windows and Doors are available in any RAL colour to suit all requirements.
